*Vertical 4 axis brush machine with 1 tufting head for the production of all kind of broom in angle shape.
*The holes in the plastic block and the wooden block should be with the holes inside.
*Thanks to 2 clamping stations in the brush machine, it will be tufting while worker can be put the plastic block in it.
*With 4 axis running by Panasonic servo motors and the whiles range of specific tooling and accessories .
描述
1) This is a big-sized broom tufting machine, the maximum length of filaments (outside holes) allowed is 180mm, while our standardized machines only process 120mm filaments.
2) It can tuft flat, curved and fan-shaped brooms. To change to make different broom models, operator just need change grippers accordingly. Please kindly note that only a set of clamps is offered with the broom machine together, free of charge, other extra grippers will be charged.
3) There are two grippers holding two brooms on worktable. Under “Automatic Mode”, it makes plastic brooms continually, non-stop. Under “Semi-Auto Mode”, it stops after it finishes a working cycle (making two brooms), and it doesn’t resume working until operator presses “Start”, which is suitable for a new opeerators.
4) Also note that the plastic broom pieces should be already molded with holes in advance. This is a tufting machine only, it can’t drill holes.
5) The machine heads travel is bigger size for the longer fialment to 150 MM
其他信息
| axis | 4 |
|---|---|
| block of broom | plastic block with holes |
| Materials of Broom Filaments | PP, PVC, PET, nylon, pig bristles |
| Tufting Method | Anchor type (flat wire) or staple type (round wire), optional |
| Motors | Panasonic servo motors |
| Touchable Screen | 5.7' touchable screen, interface is in English and Chinese, |
| Power Supply | Single-phase 220V or 3-phase 380V, 50-60Hz, 600W |
| dia of holes | 4-8 MM |
| dia of filament | 0.08-1 MM |
