Automatic Belt Loop Making Machine | High-Speed Garment Loop Production LP 08

Automatic Belt Loop Making Machine

Typical Technical Specifications

Item Typical Specification
Machine Type Automatic Belt Loop Making Machine
Main Application Production of garment belt loops, trouser loops, jeans loops, uniform loops, and narrow fabric tapes
Suitable Materials Cotton, polyester, denim, blended fabrics, twill, canvas, and elastic fabrics
Fabric Feeding Method Automatic roller feeding with adjustable tension control
Loop Forming Method Continuous folding and forming
Sewing Method Continuous lockstitch sewing
Sewing Speed Approximately 2,500–4,000 stitches per minute
Production Speed Approximately 6–15 meters per minute, depending on material and settings
Finished Loop Width Approximately 8–25 mm, depending on forming tooling
Finished Loop Length Approximately 30–180 mm, programmable or mechanically adjustable
Stitch Length Adjustable according to fabric and production requirements
Cutting Method Automatic precision knife, rotary cutter, or pneumatic cutter
Cutting Accuracy Typically ±1–2 mm, depending on fabric type and machine configuration
Feeding Control Servo motor or variable-speed motor control
Control System PLC control with digital operating panel or touch screen
Loop Length Setting Digital or mechanical length adjustment
Thread Tension Adjustable thread tension system
Motor Power Approximately 1.5–3.0 kW
Power Supply 220 V / 380 V, 50/60 Hz, according to customer requirements
Compressed Air Optional; typically 0.5–0.6 MPa when pneumatic cutting is used
Machine Dimensions Approximately 1,800 × 1,000 × 1,500 mm
Machine Weight Approximately 350–600 kg
Machine Frame Rigid welded steel construction
Automatic Functions Feeding, folding, sewing, cutting, counting, and finished-loop collection
Safety Devices Emergency stop, protective covers, overload protection, and safety sensors
Operating Mode Automatic continuous production
Application Industry Garment factories, denim manufacturers, uniform producers, textile factories, and garment accessory suppliers

Mechanical Description

The Automatic Belt Loop Making Machine is designed for the continuous production of garment belt loops and narrow fabric tapes. The machine combines automatic fabric feeding, tension control, folding, continuous sewing, length measurement, cutting, counting, and collection in one integrated system.

The fabric is fed through adjustable guide rollers and tension rollers. The forming unit folds the fabric into the required width and shape. The folded fabric is then sewn continuously by an industrial lockstitch sewing head. After sewing, the continuous tape is measured and cut into individual loops according to the preset length.

The servo-driven feeding system provides stable material transport and accurate loop dimensions. Adjustable forming plates and fabric guides allow the machine to process different fabric widths, thicknesses, and materials.

Main Mechanical Components

1. Automatic Feeding System

The feeding system includes a material holder, guide rollers, tension rollers, and a servo-controlled feeding unit. It provides smooth and continuous fabric feeding while reducing wrinkles, slipping, and material deformation.

2. Folding and Forming Unit

The folding unit consists of forming plates and adjustable fabric guides. It folds the fabric edges evenly to create a consistent belt loop width and neat appearance.

3. Continuous Sewing Unit

The sewing unit uses an industrial high-speed lockstitch mechanism. Stitch length, thread tension, and sewing speed can be adjusted according to the fabric and required seam quality.

4. Automatic Cutting Unit

The cutting unit separates the continuous sewn tape into individual loops. Cutting length can be adjusted through the control panel or mechanical setting system.

5. Servo Drive and Control System

The servo motor controls fabric feeding and synchronizes the folding, sewing, and cutting operations. The PLC control system helps maintain stable production and accurate loop length.

6. Counting and Collection System

The machine can count the produced loops and discharge them into a collection tray, conveyor, or stacking container for easy handling and packaging.

Key Features

  • Automatic continuous belt loop production
  • Stable servo-controlled fabric feeding
  • Adjustable loop width and loop length
  • High-speed industrial sewing system
  • Automatic cutting and counting
  • Suitable for denim, cotton, polyester, twill, and blended fabrics
  • Strong and neat stitched seams
  • Reduced manual labor and material waste
  • Compact structure and easy operation
  • Suitable for customized production requirements



Category: Tags: , , , , ,

Main Mechanical Components

1. Automatic Feeding System

The feeding system includes a material holder, guide rollers, tension rollers, and a servo-controlled feeding unit. It provides smooth and continuous fabric feeding while reducing wrinkles, slipping, and material deformation.

2. Folding and Forming Unit

The folding unit consists of forming plates and adjustable fabric guides. It folds the fabric edges evenly to create a consistent belt loop width and neat appearance.

3. Continuous Sewing Unit

The sewing unit uses an industrial high-speed lockstitch mechanism. Stitch length, thread tension, and sewing speed can be adjusted according to the fabric and required seam quality.

4. Automatic Cutting Unit

The cutting unit separates the continuous sewn tape into individual loops. Cutting length can be adjusted through the control panel or mechanical setting system.

5. Servo Drive and Control System

The servo motor controls fabric feeding and synchronizes the folding, sewing, and cutting operations. The PLC control system helps maintain stable production and accurate loop length.

6. Counting and Collection System

The machine can count the produced loops and discharge them into a collection tray, conveyor, or stacking container for easy handling and packaging.



Specification Value
Maximum loop length 1200 mm
Maximum mop length 1200 mm
Maximum socket width No limited
Production output 2500 mops/hour
Output for short mops (550 mm) 300 mops/hour
Power consumption 1.2 kW
Machine weight 850 kg
Dimensions (L×W×H) 1600×1200×2500 mm
Feeding method Automatic socket & staple
Yarn creel capacity 10 spools (optional upgrade)
Applicable materials Cotton yarn, recycled cotton, similar fibres,microfiber material
Voltage Customizable (e.g., 380V 3‑phase,220V 2 phase)
Weight 800 kg
Dimensions 2100 × 2000 × 2200 cm
voltage

380V/220V 50-60 HZ
production speed

3500/10 hours
belt of mop

3 Belts /4 belts
power

4000W
Min &Max mop size

700-1200 MM
