Automatic yarn rewinder / winding machine

Type: Automatic cone yarn rewinder / winding machine
Application: Bobbin yarn forming, tube dyeing preparation, post-dyeing rewinding, and special yarn winding processes
Mechanical Speed: Up to 1,200 m/min
Package Diameter: Up to 290 mm
Package Weight: Up to 3 kg
Yarn Count Range: Ne 6 – 180 (cotton, flax, wool, silk, chemical fiber)
Power: 27 kW (380V 50Hz)
Spindle Configuration: Double-sided, 12 – 72 spindles per machine
Drive: Each spindle driven by an individual AC motor with inverter control
Key Features:
- Electronic yarn detector with auto-stop on yarn break
- Automatic length fixing (max 999,999 m)
- Slow start for each spindle
- Intelligent tension control for uniform density
- Electronic anti-overlap for improved package formation
- Straight yarn path design reducing hairiness and friction

Category: Mop machine Tags: mop winder, mop winding machine

Description

Complete Yarn Processing Solutions – From Twisting to Winding

We offer a comprehensive range of textile machinery designed to streamline your entire yarn production line:

🔹 Twisting Machines – Precision-engineered two-for-one twisters delivering consistent twist counts at speeds up to 120 m/min. Ideal for cotton, wool, polyester, acrylic, and blended yarns. Features include servo-driven PLC control, electronic anti-patterning, and energy-saving spindle technology.

🔹 Rewinding Machines – High-speed automatic cone winders achieving up to 1,200 m/min with intelligent tension control and anti-overlap systems. Perfect for bobbin forming, tube dyeing preparation, and post-dyeing rewinding. Each spindle is independently driven with real-time monitoring and auto-stop on yarn break.

Whether you are twisting raw yarns into high-strength threads or rewinding packages for dyeing and weaving, our machines deliver reliability, efficiency, and superior quality – every time.

Partner with us for end-to-end yarn processing excellence.
